Guangzhou Winson Information Technology Co., Ltd.
$402-49 Others
$3050-199 Others
$25≥200Others
Model No: Z11-321
Marka: Winson
Orzecznictwo: ce
Stan Produktu: Zbiory
Rodzaje: Skaner kodów kreskowych
Typ Elementu Skanującego: CCD
Punkt Koloru: 32-bitowy
Typ Interfejsu: usb
Miejsce Pochodzenia: Chiny
Okres Gwarancji (lata): 1 rok
Serwis Pogwarancyjny: Call Center i wsparcie techniczne on-line
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Interface Type: Usb, Rs232
Max Paper Size: N/A
Optical Resolution: 1280X800 Pix
Scan Speed: 350+-50 Scans/second
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software Development Kit (SDK): NO
Interface: RS-232/USB HID KEYBOARD/USB VCP
Light Source: 8 white LEDs
Voltage Requirement: DC5V±10% ; Max 135ma
Decode Capabilities: both 1D and 2D
Scan Angle: Pitch angle:±65° Skew angle:±60° Tilt angle:±180°
Reading Accuracy: DP:1D Linear:≥3 mils 2D:≥5 mils
Dimensions: 78mm x 67mm x 54mm
Orzecznictwo: Ce
| Jednostki sprzedaży | : | unit |
| Typ pakietu | : | Pakowanie brązowe lub dostosowane (negocjowane) 1PCS/Box, 20/50pcs/karton |
| Przykład obrazu | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
|
Interface Supported
|
USB/ RS-232/TTL
|
|
Input Voltage
|
DC 5V±5%
|
|
Current
|
Max:135mA
|
|
Image Sensor
|
CMOS Array Sensor
|
|
Sensor Resolution
|
640X480 Pixels
|
|
Light Source
|
White LED
|
|
Scanning Angle
|
Pitch angle:±30°;Skew angle:±40°;Tilt angle:±180°
|
|
Field of View
|
68°(H),54°(V)
|
|
Min Resolution
|
≥5mil（PCS 0.9）
|
|
Min .PCS value
|
〉25% UPC/EAN 13（13mil）
|
